horsin: news

RF connector for PCB design

18G SMA coaxial RF connector for PCB design

With the popularity of wireless applications, the demand for SMA coaxial RF connector is growing exponentially. Board to board RF connector and SMA coaxial RF connector are among the top choices for test and measurement communication, broadcast and wireless technologies.....

RF coaxial feeder cable

How to product high performance RF coaxial feeder cable?

With the development of 5G communication industry, customers have higher and higher requirements on RF coaxial feeder cable. How to produce high-performance RF coaxial feeder cable? In fact, there are many factors to produce high performance RF coaxial feeder cable, such as high quality....

RF feeder cable

How to test RF feeder cable?

RF feeder cable has been widely used on 5G communication network , which has increasingly high requirements for RF feeder cable. Do you know how does manufacturers ensure good quality in the production process? manufacturers usually have three laboratories to test RF feeder cable: mechanical laboratory, electrical laboratory....

Antenna connector

Some kinds of antenna connector

RF connector is an common electrical connector used for signal transmission in RF applications. These connectors are used in a wide range of applications from 0 to 18 GHz. RF connector is widely used in antenna connector. All types of RF connector have a male connector and a female connector. The male connector is usually called....

Amphenol RF TNC connectors

Manufacture Similar amphenol RF TNC connectors

RF TNC connector is the threaded version of BNC connector. The connector has 50 Ω impedance, 75 ohm, Frequency is from 0-11 GHz which will show best performance. It has better performance than BNC connector at microwave frequency. Amphenol RF TNC connectors is famous manufacture on RF connector. Horsin also manufacture similar Amphenol...

SMA RF connector

What are the advantages of sma RF connector?

SMA RF connector is common connector, with a characteristic impedance of 50 ohms. If it connected with a flexible cable , the frequency can be up to 12.4 GHz. If it is connected to semi-rigid cable, the frequency is up to 18 GHz. The SMA RF connector type is widely used in aviation, radar, microwave communication ....

RF coaxial connector

Heat Treatment Process for Becu of RF coaxial connector

The Becu parts of RF coaxial connector must be heat treated process to achieve reliability of connection. Different materials and different structures are also suitable for different occasions.Beryllium bronze (Becu) is an extremely versatile precipitation hardening alloy. After solid solution and timely treatment, the strength can reach 1250-1500 MPA. The heat treatment characteristics are: good plasticity after treatment, and cold work deformation. ....

SMA connector cable assembly

Requirements and options for SMA connector cable assembly

The consideration of the SMA connector is related to the performance of RF cable . The connector interface must match the diameter of the cable. The greater difference between RF cable diameter and RF connector diameter, the worse the performance in SMA connector cable assembly....

RF jumper cable

Custom design LOW PIM low loss RF jumper cable kit

Horsin technology co,.ltd manufacture low loss low PIM RF jumper cable kits , which are the optimal choice when it comes to outdoor RF cable connectivity. By choosing the combination of our carrier approved weatherproofing and RF jumper cables, you are getting the optimal weather proofed jumper....

Applies to 5G project

RF coaxial connector applies to 5G project

5G is coming, including radio waves, optical fiber and small cellular . all of which will make 5G network equipment installation is faster, the transmission speed of 5G is about 20 times of 4G this means: industrial machinery and robot can remote control, full-length high-definition movie download...

SMA

The interface of SMA connector

The interface of SMA connector is a small interface connector, but it can work in a frequency range of up to 0-18 GHz. It is commonly used in small size, There are have 4 holes flange and 2 holes for choice, Copper plated gold for 72 hours salt spray test.

SMB

The interface of SMB connector

SMB connector can be seen as a smaller SMA version with a hoop connection structure, 50 ohm SMB usually works at 4 GHz frequency range, and 75 ohm SMB connector can work at 2GHz frequency. SMB series connectors are widely used in communication, automobile, GPS positioning, GSM mobile communication, wireless LAN equipment ect.

SMC

The interface of SMC connector

SMC RF connector is a kind of miniature RF coaxial connector which adds the thread connection from on the base of SMB. Characteristic impedance is 50ohm. The characteristic of connector is small volume, light weight, great vibration performance . they are used in connecting RF coaxial cable in radio equipment and instrument .

MCX

The interface of MCX connector

MCX RF coaxial Connector is a Kind of miniature Connectors with snap-on.Coupling Characteristic impedance has two types: 50Ω and75 Ω .The characteristic of. Connectors is in small volume, light weight, concise structure, easy to use .They are widely used in the Global base station system,Digital personal computer network, all kinds of radio. small-sized electronic equipment and WLAN system.

BNC

The interface of BNC connector

BNC connector is one of RF coaxial connector using a bayonet type coupling mechanism, characteristic impedance has two type : 50ohm and 75ohm. They can be quick connect or disconnect, reliable lock ect . they are widely used in connection with RF cable in computer field , network of wireless , medical equipment and electronic instrument .
